Commonly used in industries such as beverage, pharmaceutical, chemical, cosmetics, and food processing.
Bottle filling machine is a type of packaging machinery designed to automate the process of filling bottles with a liquid product and sealing them with caps. These machines are commonly used in industries such as food and beverage, pharmaceuticals, cosmetics, and chemicals. The main goal of these machines is to increase efficiency, accuracy, and speed in the packaging process.
It’s important to note that the design and features of bottle filling capping machines can vary based on the industry and the specific requirements of the products being packaged. When selecting a machine, factors such as production volume, bottle size, and the type of product being filled and capped should be taken into consideration.
Dolly designs and manufactures liquid filling machines to meet any application. Upgrade Your Packaging Workflow With A Fully Automated, Customized Solution. Contact us Today!
Auto Filling Capping Machine
Automatically finish the bottle filling, bottle capping. No bottle no filling feature. Suitable for liquid viscosities (gels, liquid serums, creams, powders, and more).
Filling Capping Machine
Filling Capping Machine
Filling Capping Machine
Filling Capping Machine
Filling Capping Machine
Filling Capping Machine
| MODEL | DL-GX-50 | DL-GX-4/6/8/10 | DL-BG-4/6/8/10/12 | DL-BX-500 | ||
|---|---|---|---|---|---|---|
| Filling Material | Liquid | Cream & Paste | Powder | Liquid/Paste/Powder | Liquid/Paste/Powder | / |
| Function | Filling + Capping | Filling | Capping | |||
| Productivity | 30-70BPM | 20-40BPM | 20-50BPM | 1500-2500BPH | 600-4000BPH | 0-8000BPH |
| Filling Capacity | 5-50ml | 10-50ml, 50ml-100ml, 100-150ml | 2-500g | 5-300ML | 10-100, 30-300,50-500,100-1000, 500-2500, 1000-5000ML | / |
| Filling Heads | 1/2/customized | 1/2/customized | 1/2/customized | 4, 6, 8 or customized | 4, 6, 8, 10, 12 or customized | / |
| Filling Accuracy | ±1% | ±1% | ±1% | ±2% | ±2% | / |
| Capping Rate | ≥99% | ≥99% | ≥99% | ≥98% | / | ≥98% |
| Capping Type | ROPP/Screw | ROPP/Screw | ROPP/Screw | ROPP/ Screw | / | ROPP/ Screw |
| Power | 3KW | 3KW | 3KW | 2KW | 2KW | 2.2KW |
| Voltage | 380V / 50Hz | 380V / 50Hz | 380V / 50Hz | 380V / 50Hz | 380V / 50Hz | 380V / 50Hz |
| Gas Consumption | 0.6m³/min | 0.6m³/min | 0.6m³/min | 0.6m³/min | 0.5m³/min | 0.45m³/min |
| Machine Dimension (L*W*H) | 2500*1450*1650mm | 2500*1450*1650mm | 2000*1000*1600mm | 2500*1300*1600mm | Depends on the machine | 2000*850*2050mm |
| Machine Weight | 600KGS | 600KGS | 500KGS | 800KGS | Depends on the machine | 650KGS |
Get Your Project Started by Request a Quotation or Email us at: info@dollypack.com
What Are You MAKING？
- Soft Drinks: Filling machines are used to fill bottles with carbonated and non-carbonated soft drinks.
- Juices: They are employed for filling bottles with fruit juices, vegetable juices, and other beverage products.
- Liquid Medicines: Bottle filling machines are used to fill bottles with liquid medications and syrups.
- Oral Solutions: Pharmaceutical solutions, suspensions, and elixirs are filled using these machines.
- Shampoos and Conditioners: Bottle filling machines are used to fill bottles with various hair care products.
- Lotions and Creams: Liquid and semi-liquid cosmetic products are dispensed into bottles using these machines.
- Edible Oils: Machines fill bottles with cooking oils and other edible oils.
- Sauces and Condiments: Various sauces, dressings, and condiments are filled using these machines.
- Cleaning Products: Bottle filling machines are used for filling bottles with cleaning solutions and detergents.
- Industrial Chemicals: Various chemicals in liquid form can be efficiently dispensed into bottles.
- Milk and Dairy Products: Filling machines are used for packaging milk and other dairy products in bottles.
- Motor Oil: Bottle filling machines are employed for filling bottles with motor oil and lubricants.
- Industrial Lubricants: Various industrial lubricants are efficiently dispensed into bottles.
- Bottled Water: These machines are used in water bottling plants to fill bottles with purified and mineral water.
- Wines and Spirits: Bottle filling machines are used for packaging alcoholic beverages in bottles.
- Pesticides and Fertilizers: Bottle filling machines are used for packaging liquid pesticides and fertilizers.
- Inks and Paints: Some bottle filling machines are designed for filling bottles with inks and paints.
